Wrist & Hand Trauma
- Distal Radius & Ulnar Fractures (Colles, Smith’s, Barton’s, Chauffeur’s, DiePunch)- complicated by 50% ulnar styloid Fx, TFC path, DRUJ dislocation, scapholunate lig dissociation, lunate/perilunate dislocation )
- Carpal bones Fracture & dislocations (scaphoid, triquetrum, hamate Fx &Lunate/perilunate dislocation)
- Ligaments dissociation (Scapholunate dissociation, Lunotriquetral instability)
- Metacarpal & Phalangeal fractures (Bennett, Rolando, Game keeperFx/Stener lesion, Boxer Fx)
- Pediatric wrist injury (green-stick Fx, Torus Fx, Bowing/plastic deformity, Salter-Harris injuries)
- In all cases, Orthopedic hand surgical referral is required
- Colles fx: m/c d/t FOOSH+pronation. m/c inOSP/elder women. Rare in men and if occurs need DEXA to avoid hip Fx etc. Young pts: high-energy trauma. Typically extra-articular.50%-cases show Ulna styloid (US) Fx.
- Complications: dinner fork deform, CRPS, DJD, nerve entrapment.
- Imaging: x-rad is sufficient, CT in complex Fx, MRI helps with ligament tears and TFC.
- Rx: if extra-articular and <5-mm distal radius shortening and <5-degree dorsal angulation closed reduction+casting is sufficient. ORIF in complex cases.
- Image Dx: distal rad impaction/shortening,dorsal angulation of distal fragment, carefully examine if intra-articular extension, 50% US Fx
- Smith Fx: Goyrand in French literature. Considered as reversed Colles, otherwise almost identical I.e. 85% extra-articular, 50%US Fx, OSP/elder women, young pts-high-energy trauma. Differences: mechanismFOOSHwith flexed wrist thus m. less frequent.
- Imaging steps: (see Colles Fx) C
- Complications: similar to Colles Fx
- Rad Dx: 85% extra-articular with volar(anterior) angulation of the distal fragment,radial shortening. Carefully examine cortical breach suspecting intra-articular extension that can be named as Smith type 2 or Reversed Barton Fx (next)
- Rx: similar approach as in Colles.
- Barton fx: FOOSH, impaction of distal radius similar to Colles but the Fx line extends from the dorsal radial aspect into radiocarpal joint resulting with dorsal slip/dislocation of the carpus.
- Imaging: 1st sept x-radiography often with CTto examine intra-articular Fx extension and operative planning
- Rad Dx: distal radius Fx extending from dorsal into the radiocarpal joint with a variable degree of displacement, the proximal slip of the carpus
- If Fx line extends from the volar aspect into the wrist joint named Reversed Barton aka Smith type 2 (above bottom image)
- Complications: similar to all distal radius Fx
- Rx: operative with ORIF
- Chauffeur’s/backfire Fx aka Hutchinson Fx: intra-articular Fx of Radial styloid. The name derives from the time when the car had to be started with a hand crank that could backfire inducing wrist dorsiflexion and radial deviation.
- Imaging: x-radiography is sufficient. CT may be helpful if Fx not readily shown by x-rays.
- Complications: non-union, malunion, DJD,scapholunate dissociation,lunate/perilunate dislocation
- Rx: operative with percutaneous lagscrewin all cases d/t intra-articularnature
- Die-Punch Fx: impaction Fx by the Lunate bone into distal articularLunate fossa of the Radius. IntraarticularFx. Derives its name from a technique to shape (impress) a hole in industrial machining “die-punch”.FOOSH injury.
- Imaging: 1st step x-rays, may be equivocal d/t subtle depression of the Lunate fossa then CT scanning is most informative.
- Rad Dx: impacted lunate fossa region with intra-articular Fx extension. This can present as a comminuted Fxarticular Fx of the Distal Radius.
- Rx: operative d/t intra-articular Fx
Construct arcs of Gilula when evaluating carpal injuries. An Important step required to avoid missing subtle changes in carpal alignment and cortical continuity
- Scaphoid bone Fx: m/c Fx carpal bone. D/tFOOSH wrist extended radially deviated. Location of Fx is most important to prognosis: Waist-m/c location (70%). May have 70-100%chance of AVN. Proximal pole Fx: 20-30% with a high risk of non-union. Distal pole-10%shows better prognosis. Distal pole Fx is m/c in children. Key clinical sign; pain in the snuffbox.
- Imaging: 1st step-x-radiography but 15-20%missed d/t occult Fx. Special views required. Thus MRI is the most sensitive and specific for early occult Fx. Bone scintigraphy has98/100% specificity & sensitivity esp. 2-3 days after the onset. Key rad. Dx: Fx line if evident, displacement and obscuration of scaphoid(navicular) fat pad, examine for scapholunate dissociation. If proximal bone appears sclerotic-AVN occurred. MRI: low on T1 & high on T2/STIR/FSPD d/t bone edema, a low signalFx line can be noted.
- Rx: Spica cast should be applied if clinically suspected even w/o x-ray findings. For waistFx-cast for 3-mo for prox pole 5-mo immobilization. ORIF or percutaneous pinning with a Herbert screw.
Scapholunate Ligaments Dissociation
- SNAC wrist: scaphoid non-union advanced collapse. Often d/t non-union and dissociation of scapholunate ligaments (SLL)with progressive radiocarpal and intercarpalDJD. The Proximal scaphoid fragment is attached to Lunate with distal dissociating and rotating‘signet ring” sign on x-rays.
- SNAC wrist may often result in DISI
- Rx: progressive DJD may lead to four-corner arthrodesis
- Scapholunate advanced collapse (SLAC wrist): SLLdissociation with progressive intercarpal and radiocarpal DJD and volar or dorsal carpal displacement (DISI & VISI). Causes: trauma, CPPD, DJD,
Kienbochdisease (AVN of Lunate), Preiserdisease (AVN of Scaphoid).
- SLL dissociation will lead to Dorsal or VolarIntercarlate aka Intercarpal Segmental Instability (DISIor VISI).
- Rad Dx: Dx underlying cause. X-rays demonstrate dorsal or volar angulation of the Lunate with increased or decreased scapholunate angle on the lateral view. On frontal view: Terry Thomas sign or widening of scapholunate distance 3-4-mm as the upper limit of normal.
- MRI may help with ligament evaluation and pre-surgical planning
- Rx: often operative with late DJD. Four-corner arthrodesis
- Triquetrum Fx: 2nd m/c carpal bone Fx. M/C dorsal aspect is avulsed by
toughDorsal radiocarpal ligament. Cause: FOOSH.
- Imaging: x-radiography wrist series
aresufficient. Best revealed on the lateral view as an avulsed bone fragment adjacent to the dorsum of the Triquetrum. CT may help if radiographically equivocal.
- Rx: conservative care
- Complications: rare, may persist as pain on the dorsum of the wrist
- Hook of the Hamate Fx: m/c occurs in batting sports (cricket, baseball, hockey, impact by a golf club etc.) 2% of carpusFx.
- Imaging: x-radiography may fail to detect an Fx unless “carpal tunnel view” is used. CT may help if x-rays unrewarding.
- Clinically: pain, positive pull test, weak painful grip. Deep ulnar n. branch
maybeaffected within the Guyon canal.
- Rx: usually non-operative, but chronic non-union may require excision.
- DDx: bipartite hamate
- Lunate vs. Perilunate dislocation: Lunate is m/c dislocated carpal bone. Overall infrequent carpal injury. However, often missed!
- Occurs with FOOSH and wrist extended and ulnar deviated. Imaging: 1st step x-rays. Ifunrewarding or require more complex injury evaluation CT scanning.
- Key Rad DDx: DDx Lunate from perilunate dislocation. Lunate dislocation: lunate lost its contact with distal radius ‘spilled teacup” on the lateral. Perilunate dislocation: Lunate maintains its contact with distal radius despite the Capitatedorsally dislocated. Lunate dislocation is additionally helped to identify a “pie sign” d/t Lunate overlapping the Capitate
- Rx: emergency reduction and operative repair of torn ligaments
Metacarpal & Phalangeal Injuries
- Bennett Fx: intra-articular but noncomminuted impact-type Fx of the base of 1st MC bone of the thumb. Xradiographyis sufficient.
- Rad Dx: characteristic triangular fragment of bone on the ulnar aspect of the 1st MCbase, often with radial subluxation of the remaining radial aspect of the 1st MC
- Complications: DJD, non-union etc.
- Rx: prone to instability/non-union requiring an operative care
- Rolando Fx: aka comminuted Bennett with Y or T-configuration. More complex injury. It is unstable requiring operative care
- Gamekeeper thumb: traditionally described as a chronic tear of the
ulnar(medial) collateral ligament at 1stMCP in English Gamekeepers’ who performed neck twisting/killing of small game. An acute injury may also be named as Skier’s thumb. This injury can be ligamentous w/o a fracture and/or an avulsion injury at the 1st proximal phalanx base.
- Complication: Stener lesion or displacement of torn ligament over Adductor pollicis muscle that cannot heal w/o surgical repair. MRI Dx is required.
- Avoid thumb stress views that can induce a Stenerlesion
- Imaging: x-radiography followed by MRI to Dx Stenerlesion. MSK US can be used if MRI unavailable.
- Stener lesion on MRI & MSUS: ulnar collateral stump is more superficial to Adductor pollicis aponeurosis and appears like a low signal mass-like stump forming so-called “yo-yo on the string sign” reported both on MRI and MSK US.
- Rx: often operative
- Boxer Fx: m/c MC Fx. An extra-articular usually non-comminuted or minimal comminuted Fx through m/c the 5th and sometimes the 4th MCneck-head junction (occasionally through the shaft) resulting in volar head angulation. Mechanism: direct impact as in clenched fist punching hard surface (e.g facial bones/wall punching) hence 95% in young males.
- Imaging: x-radiography hand series is sufficient
- Rad Dx: Fx line transverse or oblique through MCneck with volar head angulation. Evaluate the degree of displacement, critical to report.
- Rx: typically non-operative with short –arm gutter splint and digits flexed. (www.aafp.org/afp/2009/0101/p16.html)
- N.B. If the same mechanism fractures the 2ndand 3d MC in the same anatomic area it may require operative care.
- Phalangeal hand Fx: m/c skeleton Fx (10% of all Fx). Sports and industrial injuries dominate
- Imaging: x-radiography with hand series or PA/lateral finger views will suffice
- Rad Dx: if prox phalanx Fx, distal fragment is angled
volarlywith prox fragment dorsally. Distalphalanxmay be angled dorsally. Key observation: nail bed injury, which considered an open Fx with risk of infection.
- Rx: if <10-degree angulation-buddy-taping with motion rehab. CRPP vs ORIF can be considered in complex cases-Orthopedic hand surgeon referral
- Complication: loss of motion, necrosis, infection.May result with amputation
- For additional common injuries: PIP is m/c dislocated joint. Mullet (Baseball) finger,
Jerseyfinger and other injury refer to:
- Felon: septic infection of the fingertip pulp typically with Staph.Aureus. Causes: needle prick(diabetics), paronychia, nail splinters etc. m/c in index and thumb, presenting with pain, swelling etc.
- D/t specific pulp anatomy theinfection>swelling leads to pulp compartment syndrome-pressure and necrosis.
- Rx: operative with incision distal to DIP, irrigation/debridement
Pediatric Wrist Injury
- Incomplete Fx: Greenstick Fx, Torus (Buckle)Fx, Bowing (Plastic) deformity/Fx. D/t FOSHe.g. fell off the monkey bar. m/c affects <10-years-old.
- Key Imaging diagnosis: degree of angulation/displacement, epiphyseal growth plate injury (Salter-Harris classification)
- Rx: usually non-operative (closed reduction and casting)
- Distal Radioulnar Joint (DRUJ) Instability-common injury following trauma as in FOOSHwith wrist hyperextension and rotation and disruption of DRUJ ligaments and TFCcomplex. Avulsion of ulnar styloid with the dorsal or volar displacement of distal ulnar should be noted.
- Imaging steps: x-rays initially, MRI may identify ligaments and TFC damage, MSKUScan help with ligaments tearing.
- Note: isolated DRUJ volar (top image) and dorsal (bottom image) dislocation.
Wrist & Hand Arthritis
- Wrist DJD-typically secondary to trauma, scapholunate dissociation, SLAC, SNAC wrist, CPPD, Keinboch or Preiser Disease and others.
- May lead to major functional loss
- Imaging: typically presents as radiocarpal JSL, subchondral sclerosis,osteophytosis, subcortical cysts, and loose bodies. Typically additional induces intercarpal degeneration and particularly Tri-scaphe joint.
- MRI may be helpful with early recognition of scapholunate dissociation, Lunate/Navicular AVN.
- Rx: conservative vs. operative.
- DJD Hand: Extremely common. True primary OA. MCP-never affected w/o DIP & PIP
- If isolated MCP OA noted considerCPPD & Hemochromatosis (Hook-like osteophytes)
- Mid-age females
- Typically painless except 1st CMC OA
- DIPs-Heberden nodes, PIPs-Bouchard nodes
- Erosive OA (occasionally called“inflammatory OA”)
- A Spectrum of OA but producing central proximal erosions at DIPs and PIPsresulting with very characteristic “gullwing” appearance. No systemic inflammation (no CRP, RF, Anti-CCP Ab)typically in middle-aged/elderly females, like Hand OA, often seen in families
- involvement (lung, CVS, Ocular, Skin etc.) Pathology: Tcell>Macrophage/APC>mediatedautoimmune process resulting in pannus formation and gradual destruction of ST, cartilage, bone,
andother tissues. 3% FemalesVS.1% Males. Environmental triggers: infection, trauma, smoking, and others in a genetically susceptible individual. 20-30%may be disabled after 10-years.
- Dx: clinical, labs, imaging.Symmetrical Polyarthritis esp. in MCP, wrists (2nd & 3RD MCP)
